6GHz Antenna and Cable Analyzer,SK-6000-TC
-Battery : Lithium-ion rechargeable — 10 Hrs Typical Operating Time

- Weight : 1.98 (lbs) 0.9 (kg)

-Easy to operate and field ready for first-time, occasional and experienced users.

-FDR (Frequency Domain Reflectometry) measurement method results in a highly reliable assessment of the health of critical components in your system; ultimately providing a “heads-up” before a failure occurs.

-Fault location or DTF mode indicates VSWR or Return Loss levels at each point along the cable and antenna system length.
Cable Loss function measures insertion loss of the cable system over a given frequency range.

-Units cover frequency ranges of 20 MHz - 6000 MHz.

-USB communication port for connection to storage device.

-Three Year Warranty



리튬밧데리 완충전 후 10시간 사용, 총 무게 0.9kg Handheld type


Standard Accessories: AC Adapter (12 Vdc Output), Hard Carrying Case, RF Cable - 1.0 Meter long, Instruction Manual, Soft Carrying Case, USB Drive, USB Interface Adapter, Stylus and Calibration Combo



  • Suitable for use in Worldwide Cellular and PCS/DCS systems; supporting measurement of CDMA, GSM, and LTE Protocols.
  • Other applications include 3G, Broadcast, Government, Tactical Military, Microwave, Paging, Public Safety, Trunking, WLAN, and TETRA

[Product Specification]
 Item No SK-6000-TC
 Item Name Antenna and Cable Analyzer
 Frequency Range 20-6000MHz
 Frequency Resolution 1kHz
 Frequency Accuracy ±2.5×10-6 @25°C
 Output Power
10dBm ±1.5 dB
 Reflect Amplitude Accuracy –15 dB to 0 dB: 0.4 dB; –25 dB to –15 dB: 1.5 dB; –35 dB to –25 dB: 4.0 dB
 Trace Noise Magnitude 0.05 dB rms
 Measurement Speed 1 ms / data point
 Measurement Points 51 to 3201
 Measure Bandwidth
100 Hz to 30kHz
 Temperature Stability 0.01 dB/°F; 0.02 dB/°C
 Return Loss Measurement  Range 0 dB to -60 dB
 Resolution 0.01 dB
 VSWR Measurement Range
1.0 to 65.0
 DTF Range 0 to 5000 (ft); 0 to 1500 (m)
 Test Port Connector    Impedance N-type, Female 50 ohms
 Connector USB Type-C, USB 3.0
 Languages English, Chinese, Spanish
 Recommended Calibration  Interval 3 year
 Dimensions 7.7 x 3.6 x 2.4 (LxWxH—inches); 195 x 90 x 60 (LxWxH—mm)
 Weight 1.98 (lbs) 0.9 (kg)
 Maximum Input Voltage
 Operates In Temperature 14°F to 131°F (–10°C to +55°C)
 Storage Temperature –40°F to 176°F (–40°C to +80°C)
 Battery Charging  Temperature 32°F to 95°F (0°C to +35°C)
 Altitude Up to 15000 ft (4600 m)
 Humidity 95±5° max (non-condensing)
 Power Measurement
 Storage Capacity Thousands of Traces and Setups
 Immunity to Interfering  Signals 13dBm
 CE EMC – Standard EN 61326-1:2006; Safety – Standard EN 71010-1:2001
 Battery Lithium-ion rechargeable — 10 Hrs Typical Operating Time
 Battery Charge Time 5 Hrs for Full Charge
